The built-in validation in Silverlight 3.0 is a great new feature that can be used on essential Silverlight controls such as TextBox. Using this feature, it is possible to nicely display an error message and highlight the TextBox that has bad value.
In this post I will only cover validating data in TextBox controls, which are simply used in most forms to receive basic information such as Name, Surname and Email address. The completed and working version of this project can be downloaded from CodePlex from here. I will explain and provide solution on how to validate ComboBox, Radio Button controls or etc in another post soon, so please keep yourself updated on new posts here.
1. Create a basic form with a few TextBox controls in the xaml
2. Create a class, call it CustomValidation
Add the following code to your CustomValidation class:
public CustomValidation(string message)
{
this.message = message;
}
public bool ShowErrorMessage
{
get;
set;
}
public object ValidationError
{
get
{
return null;
}
set
{
if (ShowErrorMessage)
{
throw new ValidationException(message);
}
}
}
3. Create an Extension class (Extensions)
To understand what is an Extension class and for more information about them visit my tutorial post “Extension methods in Silverlight and C#”.
In brief: Extensions will be your Extension class to extend any object of type FrameworkElement like TextBox controls within your application framework. It means you can use the public methods within this class as a “built-in” method for your TextBox.
Create a static public method and call it SetValidation. This method receives an instance of a FrameWorkElement and a string value, and returns nothing:
{
CustomValidation customValidation = new CustomValidation(message);
Binding binding = new Binding(“ValidationError”)
{
Mode = System.Windows.Data.BindingMode.TwoWay,
NotifyOnValidationError = true,
ValidatesOnExceptions = true,
Source = customValidation
};
frameworkElement.SetBinding(Control.TagProperty, binding);
}
CustomValidation is the class we defined earlier.
“Binding” is a class in System.Windows.Data assembly which gets or sets a value that indicates whether to raise the error attached event on the bound object.
What are we doing? Here we have a CustomValidation class that has one property (“ShowErrorMessage”) and one public methods (“ValidationError”). “ValidationError” is our source binding object and what we want to be able to do in the future is to bind our frameworkElement, which is a TextBox, to ValidationError. We are in simple words binding the CustomValidation class to our TextBox once we call this method on our TextBox.
For more information on Binding and BindingExpression visi msdn article here.
Create another two methods for displaying validation error and also for clearing validation error when the error was corrected:
{
BindingExpression b =
frameworkElement.GetBindingExpression(Control.TagProperty);
if (b != null)
{
((CustomValidation)b.DataItem).ShowErrorMessage = true;
b.UpdateSource();
}
}
public static void ClearValidationError(this FrameworkElement frameworkElement)
{
BindingExpression b =
frameworkElement.GetBindingExpression(Control.TagProperty);
if (b != null)
{
((CustomValidation)b.DataItem).ShowErrorMessage = false;
b.UpdateSource();
}
}
By creating a new BindingExpression you will be creating an instance of your binding so you can control the properties and public methods of your binding source/target. In above case, we are casting the BindingExpression.DataItem as CustomValidation. This enables us to access the properties of this class, “ShowErrorMessage” in this case.
4. RaiseValidationError() and ClearValidationError()
So now we have our TextBox, a method in our Extension class to bind the TextBox to our CustomValidation class and passes our error message, and a method in our Extension class that fires throw new ValidationException(message); from the CustomValidation class.
All we need to do now is to check if a specific TextBox is valid or not. If the TextBox was not valid we can simply use the RaiseValidationError() and ClearValidationError() methods, which should now be available from the intellisense in Visual Studio, to throw the validation exception and display a suitable error message and we do that by following code when the submit button was pressed:
bool isFormValid = true;
if (Name.Text == “”)
{
Name.SetValidation(“Please enter your name”);
Name.RaiseValidationError();
isFormValid = false;
}
use isFormValid variable to check if you have to submit the form or not. The Name.ClearValidationError() makes sure you clear the form everytime you press submit, so if the form was valid the error message had already been cleaned.
I have some extra validation extensions on this project and have organised the code in different class files. Download the project from here.
